Panasonic S/U-71PT3E/R5

Cooling Capacity: 7.10 kW (2.0 – 7.7 kW)

Heating Capacity: 7.10 kW (2.1 – 8.1 kW)

Airflow (H/M/L): 501 / 434 / 367 L/s

Indoor Unit Dimensions (H x W x D): 360 x 1200 x 700 mm

Outdoor Unit Dimensions (H x W x D): 695 x 875 x 320 mm

Power Supply: 240V / 1 Phase / 50Hz

Power Supply Connection: Outdoor

Max Current (Outdoor Unit): 14.8 A

Refrigerant Type: R32

Pipe Sizes (Liquid/Gas): 6.35 / 15.88 mm (Indoor unit requires 9.52 to 6.35 reducer for liquid, supplied in box)

Min/Max Pipe Run: 3 m / 40 m

Pre-Charged Run: 30 m

Additional Refrigerant Charge: 17 g/m

Max Elevation (OU Higher/Lower than IU): 15 m / 30 m

Supply Air Connection (H x W): 266 x 1024 mm

Return Air Connection (H x W): 266 x 1024 mm

Weight (Indoor Unit): 36 kg

Weight (Outdoor Unit): 50 kg

7.1 kW Cooling | 7.1 kW Heating

Panasonic 7.1kW S-71PE3R / U-71PZ3R5 High Static Ducted Air Conditioner System | 1 Phase

Consisting of an outdoor unit and a concealed indoor unit, a ducted system delivers air through ducting pipes (usually in the ceiling) into each room via vents on the floor, wall or ceiling. Panasonic ducted systems look very discreet and have been designed with flexibility in mind, which is extremely helpful when designing a system for your home, and also makes installation much easier. A Panasonic ducted air conditioner will provide years of comfort for you and your family, and it will add value to your home as ducted air conditioning is a highly desirable feature for home buyers.

Experience an outstanding operating temperature range. Cooling is possible even at an outside temperature of 48°C and heating possible even at a freezing -20ºC. Panasonic outdoor units are built to last in the harsh Australian environment. Internal components are built to withstand the damaging effects of salty air, dust, wind and rain. Panasonic Air Conditioning is amongst the quietest in the world. Both our indoor and outdoor units have been engineered to ensure you get a peaceful night’s sleep.

• Panasonic Inverter technology
• Compact and flexible design
• High Static Ducted
